Air Handling Unit
Description
Air Handling Units are mainly used for maintaining air quality (cooling, heating, humidifying, dehumidifying, filtration etc.), air quantity (Cubic Meter per Hour (CMH) or number of Air changes per hour) and for circulation of air in the specified area through properly designed air distribution network. AHUS with various combinations of airflow, static pressure and varied selections of filtration level can be built to match customer requirements. These units are designed to offer customized solutions to suit requirements.
In a standard construction of AHU, the casing consists of double skin sandwich insulated (PUF) panels which are mounted on specially designed anodized aluminum profile structure and the casing is mounted on Galvanized iron base frame with fan, motor, cooling / heating coils, volume control dampers and filters (as per the classification required) and stainless steel drain pan, for condensate disposal.
Additional features like Heat Recovery Wheel, Heat Pipes, Plate type heat exchangers, Sound Attenuators, Motorized Damper with Actuators, Fire Control Dampers, Variable Frequency Drive Control Panels, etc., can be offered as per the requirement
Chill Water Coil
Electric Heater
Air Damper
DX Cooling Coil
Standard & Custom designs
Built : in automation controls
Superior design,
Precise workmanship,
Low maintenance,
Highly reliable
Types :
– Single Skin A.H.U.
– Double Skin A.H.U.
– Ventilation Type
– Exhaust Unit
– Fresh Air Unit
– Treated Fresh Air Unit (T.F.A.)
Energy efficient fan and motor option:
– Plug fans
– Belt DIDW fans
– EC Fans
Food grade rubber gaskets
Temp. Range : -17 C to 50 C
Humidity Range : 40 5 to 70 5RH %
Stage Of Filtration : 20 ,10 , 5 , 0.3 , 0.1
Puff Density : 40 2kg/m3
Structure : Galvanized And S.S.304
Aluminum Anodized Structure
Range :- 800 Cfm to Site Condition
Hospital and Healthcare
Pharmaceutical
Chemical Industry
Food Industry
Solar Industry
Semi Conducting Industry
